Specification for R1 Version 1.0 2025 | ||
Catagory | Item | Specification |
Display | Light source | LED |
LCD panel | 3 inch | |
Light source life | 30000 hours | |
Lens | Glass lens | |
Native resolution | 1920x1080 pixels, support 4K | |
Brightness | 250 ANSI lumens | |
Focus mode | Auto focus and electric focus | |
Keystone correction | Auto up and down /electric 4D keystone correction | |
Zoom | Digital zoom | |
Interface | USB*1/HDMI *1/3.5mm audio output | |
Working Noise | <38 db/m | |
Working temperature | 0℃-40℃ | |
Projection Images | Aspect ratio | 16:9, 4:3 |
Throw ratio | 1.32:1 | |
Projection distance | 1.2-5 meters | |
Projection screen size | 40-180 inches | |
Audio | Built-in speaker | 5W*1 speaker |
Audio output | 3.5mm Stereo Jack | |
Bluetooth | BT5.2 | |
Bluetooth speaker mode | yes | |
Software solution | CPU | Amlogic T950D4 |
RAM+ROM | 1+8G | |
Wifi | Dual Band Wi Fi (2.4 Ghz + 5 Ghz) support Wi Fi6 | |
Licensed Android 13.0 | Connect to phone or PC via HDMI; Connect to TV box or TV stick ; Play video by USB flash disk; Connect with 2.4G/5G Wi-Fi; Mirror screening; Certificated apps like Netflix, YouTube, Prime Video and so on; Start up guide | |
Mechanical design | Projector color | Black |
Projector mount | 360° Rotatable bracket, UN1/4 | |
Power | Power input | 100~240V-50/60Hz |
Power consumption | 70W | |
Battery for remote | AAA battery *2 (Not included) | |
Accessories | AC power cords | 1 |
Manual book | 1 | |
Bluetooth remote | 1 | |
Colorful packaging box | 1 | |
Packing information | Quantity per carton | 8 pieces |
unit size | 225*62*219mm | |
packaging size | 240*130*255mm | |
carton size | 650*300*595mm | |
Nett weight/unit | 1.2KG | |
Gross weight/unit | 1.6KG | |
Nett weight/carton | 12.8KG | |
Gross weight/carton | 14KG | |
